Product Description
Processing range
Width:≤1300mm
thickness:≤50mm(customizable)is basically not limited
Length:no linited
Power part
Belt drive motor*sets:18.5KW
Platform lifting motor *1set:chuangwei 86BYG250-156
Feed conveying motor "l set:4kw
Brush roller rotation motor *3:4.5kw
Brush roller lifting motor *l set:Chuangwei86BYG250-156
Brush roller revolution motor1 set:VTV200W-100JB20G15 380v
Overall power:47kw
Eccentric cots:Effective 1360mm* diameter 240mm* glue layer20mm
Power of dust removal fan *1:7,5kw(optional)
Operational parameter
Sand Belt speed:≈1100m/min
Feedingspeed:0.5-7.5m/min
Attachment
Abrasive belt size:2200mm*1310mm
Conveyor belt size:6870mm*1300mm
Emery cloth silk wheel "6 groups:320mm*320mm*32mmautomatic
Thickness adjustment mode:Automatic
Others
Pulse dust collector :(filter cartridge *4) (optional)
Thickness adjustment accuracy:<0.05mm
Working air pressure:0.4-0.6Mpa
Peripheraldimension
Size:4100mm*1700mm*2300mm
Weight:4200kg
Our Services
We have a professional service team and 24-hour online service, which supports face-to-face training and online training.
Company Information
EJON was founded in 2011 ,it consists of a group of young people from all corners of the country with an average age of 36. EJON started as a slotting machine, and has developed to this day, becoming a technology company with independent research and development capabilities and manufacturing capabilities in the entire industrial chain of advertising equipment. Its main products include slotting machine, letter bending machine, piercing machine, letter shell grinding machine and piercing machine. Products from the initial step motor control to single servo control, developed to the top configuration of 8 servo control now. Products are sold to more than 100 cities and regions around the world. After more than ten years of development, EJON has become the world's largest advertising equipment manufacturing and sales company integrating R&D, design, manufacturing, sales and export. Among them, slotting machines and word bending machines rank first in the world, with customer satisfaction above 95% and repurchase rate of 53%.
EJON has formed a long-term strategic partnership with Huichuan, Delta, Panasonic, Fuji and other companies. At the same time, we adopt the 1500-ton integrated die-casting technology of the same level as TESLA to ensure that the products have superior stability. The comprehensive use of integrated die casting technology endows our products with inheritance attributes. Only an ordinary slotting machine can easily inherit three generations in the hands of users, while ensuring that the equipment is still in good use.
With the advent of the post-epidemic era, EJON shoulders greater social responsibility, takes "benefiting the public" as its own responsibility, works hand in hand with strategic partners, and is committed to reducing costs and increasing efficiency, benefiting global advertising logo manufacturers, and providing customers with products with stable performance, high efficiency, quickness, simple operation and inheritance, Hui Ze 3rd generation, 24-hour online worry-free after-sales service around the world, with the ultimate goal of serving global advertising logo manufacturers.
