Product Details:
|
| Condition: | New | Video Outgoing-inspection: | Provided |
|---|---|---|---|
| Machinery Test Report: | Provided | Marketing Type: | New Product 2022 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Motor |
| Material / Metal Processed: | Aluminium Alloy, Aluminum, ALLOY, Brass / Copper, Stainless Steel, Carbon Steel, Stainless Steel,Galvanized Sheet,Aluminum Plate, | Automation: | Automatic |
| Year: | 2022 | Warranty: | 1 Year |
| Weight (KG): | 700 | Key Selling Points: | Multifunctional |
| Applicable Industries: | Advertising Company, Restaurant, Construction Works , Building Material Shops | Showroom Location: | Egypt, Turkey, Viet Nam, Brazil, Saudi Arabia, India, Russia, Spain, Thailand, South Korea, Ukraine, Malaysia |
| Machine Type: | Roller-Bending Machine | Product Name: | Channel Letters Bender Machine |
| Thickness: | 0.4-1.2mm | Height: | 200-200mm |
| Slotting: | Front And Back Both Sides Slotting | Processing Material: | Stainless Steel, Galvanized Plate, Aluminum Plate And Profile |
| Operation Principle: | High Precision Automatic Feeding | Bending System: | Double Blade Alternate Bending System |
| Package Size: | 1410*780*1600mm | Control System: | 7 Axis Control System (3 Servo Axis Control) |
| Port: | Tianjin Shanghai Shenzhen Qingdao |
SPECIFICATIONS | ||||||
Feeding system | Double ball-screw alternate feeding system | |||||
Slotting System | Plane cutter and alloy milling cutter (double sides cutting) | |||||
Bending System | Double blade alternate bending system | |||||
Suitable Material | Stainless steel, Galvanized steel, Aluminum plate, | |||||
Material Height | 20-200mm | |||||
Material Thickness | 0.4~1.0mm | |||||
Accuracy | ±0.1mm | |||||
Min. Bending Angle | R6 | |||||
File Format | Dxf. | |||||
Power | AC220V、50Hz、2.0Kw | |||||
Weight | 700KG | |||||
Control System | 7 axis control system (3 servo axis control) | |||||
The double feeding holder ensures the smooth feeding and avoid warping.
The monobloc casting of Bending Mechanism has high molding degree which ensure the bending speed and stability.
Double-cutter slotting, using plane cutter for Galvanized sheet and Stainless steel, using milling cutter for Aluminum plate and Aluminum profiles.
Steel coupling ensures the bending molding and bending speed.
To use the device, you need to install the control card in your computer and then connect to the bending machine and install the software.
Computer configuration : XP system or window7 32-bit system, and requires a PCI card slot to install the control card.
The use of equipment should be equipped with air compressor, we suggest that the selection of more than 4kw, the gas flow is 0.6m³/Min.
The software of bending machine is self-developed. Import file format supports .Dxf.Plt .AI.
We recommend using Coredraw or Adobe illustrator to complete the file after exporting file to.Dxf.Plt.Ai format. Then open the operating software, select the document.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to install and use the machine.
* Engineers available to service machinery overseas.
Packaging | ||
Size | 1410(L) * 780 (W) * 1600(D) | |
Weight | 700 | |
Packaging Details | The normal package is fumigated wooden box(Size: L*W*H). If the container is too tight, we will use PE film for packing or pack it according to customers' special request. | |
